4 Txoj Kev Valve
Qhov no 4-txoj kev hluav taws xob dej valve / plaub-txoj kev coolant tswj valve yog lub hauv paus tseem ceeb ntawm kev tswj hwm ntawm lub tsheb ntse thermal tswj system (BTMS), thiab yog tsim los rau cov kev cai ntawm lub tsheb lub coolant ncig nyob rau hauv ob qho tib si lub zog tshiab tsheb thiab ib txwm roj tsheb.
Hauj lwm lawm
Yog tias koj tab tom nrhiav rau 4 txoj kev valve, txais tos rau cov khoom muag los ntawm peb lub hoobkas. Raws li ib qho ntawm cov ua lag luam thiab cov muag khoom nyob rau hauv Suav teb, peb yuav muab koj cov kev pabcuam zoo tshaj plaws thiab xa khoom sai. Tam sim no, xyuas cov lus hais nrog peb tus neeg muag khoom.
4 Txoj Kev Valve
Khoom Description
Lub cev valve tau txais plaub -txoj kev teeb tsa lub raj xa dej, thiab tau nruab nrog lub tshuab hluav taws xob tswj kev tsav tsheb. Nws tuaj yeem hloov tau thiab raug hloov thiab kho cov dej txias ntws, kev faib tawm thiab ntws kev hloov pauv ntawm plaub lub voj voog dej raws li qhov ntsuas kub ntawm lub tsheb ECU. Nws tuaj yeem hloov kho kom paub txog kev tswj hwm qhov kub thiab txias sib txuas ntawm cov hluav taws xob sib txawv xws li cav / peb- hluav taws xob, roj teeb pob, cua txias thiab cua sov, radiator.
| Nruab nrab | Ethylene glycol aqueous kua (50% / 50%) |
| Nruab nrab kub | -40 ° ~ 115 ° C |
| Ambient kub | -40℃~ 100 degree, txheeb ze humidity Tsawg dua los yog sib npaug rau 95% |
| Rated voltage | DC 24 V |
| Kev khiav hauj lwm voltage | DC18V ~ 30V |
| Tswj txoj kev | LIN tswj |
| Tam sim no | Nyob rau hauv qhov ntsuas hluav taws xob DC24V, kev khiav hauj lwm tam sim no Tsawg dua lossis sib npaug rau 500mA, lub zog tam sim no Tsawg dua lossis sib npaug rau 1000mA |
| Hloov sijhawm | Nyob rau hauv qhov ntsuas hluav taws xob DC24V, hloov lub sijhawm Tsawg dua lossis sib npaug li 10s |
| Sab hauv to | Nyob rau hauv 30kPa siab sib txawv nrog ethylene glycol aqueous tov (50% / 50%), sab hauv to tsawg dua los yog sib npaug rau 20 L / min |
| Sab nraud to | Nyob rau hauv 340kPa (gauge siab) siab, roj to tsawg dua los yog sib npaug li 5 L / min. L / min |
| Flow kuj | Tsawg dua lossis sib npaug li 12kPa 0.20L / min |
| Suab nrov | Raws li qhov ntsuas hluav taws xob, nrog lub valve tsis ntws nrog cov xov xwm, sim ntawm qhov deb ntawm 500mm los ntawm lub valve, suab nrov tsawg dua lossis sib npaug li 45dB(A) |
Khoom tsim
1. Plaub-txoj kev tsim kua dej:Ib tug ntoo khaub lig-zoo li plaub- txoj kev sib xyaw dej hauv Circuit Court layout nrog ntau cov kav dej sib xyaw ua ke thiab sib sau ua ke. Nws tso cai rau kev tswj hwm ib txhij thiab ywj pheej ntawm ntau cov lus qhia thiab qhov ntim, ua kom yooj yim rau tag nrho lub tsheb txias yeeb nkab layout, txo qis cov yeeb nkab fittings sab nraud thiab qhov txaus ntshai, thiab optimizing qhov chaw siv.
2. Integrated electronic control sealed vaj tse tsim:An integrated waterproof electronic control drive module + high-strength corrosion-resistant engineering plastic valve body, coupled with a dedicated sealing lock and anti-corrosion fastening screw design, resists aging and high/low temperature coolant corrosion, remaining stable and leak-free even under strong vibration conditions, maximizing reliability.
3. Thawj Hoobkas-qib installation tsim:Precisely aligned standard mounting qhov + universal ceev -txuas cov yeeb nkab interfaces, molded los ntawm thawj lub tsheb cov ntaub ntawv, tso cai rau ncaj qha, tsis yog - puas installation yam tsis hloov; multi-angle lub cev qauv nrog tshwj xeeb tu thiab cav compartment installation margins, ua installation yooj yim thiab ntau yam ntxiv.
Cov khoom siv
Khoom kom zoo dua
1. Precise thiab Intelligent Temperature Control:Electronic tiag tiag- lub sijhawm hloov kho ntawm ntau- channel coolant ntws thiab kev taw qhia sai sai rau kev tswj qhov kub thiab txias ntawm cov tsheb sib txawv, ua kom zoo dua lub roj teeb / lub zog hluav taws xob ua haujlwm kub ntau, txo kev siv hluav taws xob, thiab txhim kho tag nrho lub zog ntawm lub tsheb.
2. ruaj khov, ruaj khov, thiab qis- Ua tsis tiav:High-kev sib khi qauv + kev laus- tiv taus thiab corrosion- cov khoom siv lub plhaub tiv taus, tiv taus qhov kub thiab qis qis thiab cov kav dej vibration, kom tsis txhob muaj dej los yog jamming txawm tias tom qab ntev - siv sij hawm ntev, txo qis tom qab- kev muag khoom kho nqi, thiab ncua kev pab cuam lub neej deb tshaj li qhov hloov pauv.
3. Ua tau zoo Adaptability thiab yooj yim installation:Thawj lub Hoobkas tshwj xeeb tsim qauv tsim, nrog kev ua kom zoo ntawm qhov thiab cov yeeb nkab sib txuas, ua kom yooj yim installation thiab tsis tas yuav hloov kho ntxiv; dav compatibility, hloov tau rau thermal tswj systems ntawm ntau lub tsheb qauv, ua hloov thiab installation txhawj xeeb-dawb thiab siv zog.
Cov khoom siv
1. Precise Vehicle Thermal Management:
Raws li lub hauv paus hub ntawm lub tsheb txias system, nws ntse hloov ntawm ntau yam coolant flow paths, precisely tswj lub khiav hauj lwm kub ntawm lub powertrain, lub cev muaj zog, thiab roj teeb pob. Qhov no ua kom sov sai sai - nyob rau hauv cov huab cua txias thiab raws sij hawm tshav kub dissipation nyob rau hauv cov huab cua kub, guaranteeing cov tseem ceeb Cheebtsam nyob rau hauv lawv cov optimum kev khiav hauj lwm ntau yam.
2. Intelligent Multi-Circuit Water Distribution and Switching:
Kev ywj pheej txuas plaub lub kav dej loj -radiator, rhaub tub ntxhais, lub tank dej, thiab cov roj teeb cua txias- nws cia li qhib thiab kaw thiab kho cov dej ntws hauv txhua lub voj voog raws li kev tsav tsheb, ib txhij hais txog ntau yam haujlwm xws li lub zog tsheb txias, cua sov hauv tsev, thiab roj teeb kub tswj.
3. Ntau yam tsheb sib xws thiab hloov pauv:
Dav siv tau nrog cov roj teeb kub tswj cov tshuab hauv lub zog tshiab lub zog hluav taws xob / hybrid tsheb thiab lub tshuab hluav taws xob ntse ntsuas kub tswj hauv cov tsheb tsoos roj. Nws kuj tseem tuaj yeem siv rau tom qab- kev muag khoom ntawm OEM qhov tsis ua haujlwm, kev hloov kho kev ua haujlwm, thiab kev teeb tsa ua ntej - OEMs, muab kev hloov tsheb zoo sib xws thiab dav siv cov xwm txheej.
Khoom FAQ
Q1: Lub luag haujlwm tseem ceeb ntawm 4 - txoj kev plaub-chaw nres nkoj dej valve yog dab tsi?
A: Qhov no yog ib qho hluav taws xob tswj plaub-chaw nres nkoj tswj lub valve rau lub tshuab hluav taws xob ntse cua txias. Nws precisely tswj cov kev taw qhia ntws thiab ntws tus nqi ntawm coolant nyob rau hauv plaub cov lus qhia, ntse tswj qhov kub ntawm lub cav, lub hwj chim roj teeb, cua sov Circuit Court, thiab radiator, optimizing tag nrho cov tsheb thermal tswj efficiency thiab txo lub zog noj.
Q2: Cov qauv tsheb twg yog cov khoom no sib xws nrog?
A: Nws yog dav siv nrog lub zog tshiab hluav taws xob ntshiab tsheb thiab hybrid HEV / PHEV qauv, thiab kuj tau sib xws nrog ntau lub tsheb roj txhim kho lawv qhov ntsuas kub tsis tu ncua. Nws txhawb nqa ib qho -rau-ib qho tsis yog- puas tsuaj hloov ntawm OE thawj qhov chaw thiab tseem tuaj yeem siv tau tom qab- kev muag khoom kho, OEM qhov chaw, thiab kev hloov kho cov xwm txheej. Lub tsheb- cov qauv tshwj xeeb tuaj yeem muab rau kev kuaj xyuas meej.
Q3: Puas yog kev teeb tsa yuav tsum tau hloov kho cov kav dej qub?
A: Tsis yog. Cov khoom yog molded raws li lub Hoobkas thawj 1: 1 specifications. Cov haujlwm ntawm lub qhov, cov yeeb nkab diameters, thiab cov ntsaws txuas txuas tau zoo tag nrho rau lub tsheb qub. Nws tuaj yeem txuas ncaj qha rau hauv thiab nruab yam tsis muaj qhov drilling lossis cov yeeb nkab txiav. Kev hloov pauv tuaj yeem ua tiav sai ntawm cov khw kho kom zoo nkauj.
Q4: Cov khoom siv ntev npaum li cas? Puas yuav muaj teeb meem xau lossis jamming?
A: Lub cev lub cev yog ua los ntawm siab - lub zog iav fiber ntau engineering yas uas tiv taus qhov txias txias thiab kub / qis kub laus. Ua ke nrog lub siab -cov qauv sealing zoo thiab ntev - lub neej hluav taws xob tswj lub cev muaj zog, nws dhau los ua ntau lab ntawm kev qhib thiab kaw qhov ntev, qhov kub / qis, thiab kev ntsuas siab ua ntej tawm hauv lub Hoobkas, txo qis jamming thiab xau tsis ua haujlwm. Nws cov kev pab cuam lub neej sib tw thawj lub Hoobkas zoo.
Q5: Dab tsi yog qhov txawv ntawm qhov no thiab plaub - txoj kev valve?
A: Plaub-txoj kev li qub feem ntau yog kev tswj xyuas qhov kub thiab txias, thaum qhov no yog hluav taws xob ntse thiab nquag hloov kho. Nws tuaj yeem tau txais cov teeb liab los ntawm lub tsheb ECU hauv lub sijhawm tiag tiag, dynamically thiab meej faib ntau cov dej ntws, ua rau muaj kev tswj xyuas qhov kub thiab txias, txo qis zog, thiab pib lub tsheb zoo dua - nres thiab tsav tsheb.
Q6: Dab tsi yog cov khoom warranty thiab tom qab - txoj cai muag khoom?
A: Peb muab cov qauv kev lag luam warranty lub sijhawm. Rau qhov tsis yog-tib neeg- ua rau muaj teeb meem zoo, peb txhawb kev hloov / rov qab. Cov ntsiab lus tshwj xeeb warranty tuaj yeem sib tham rau kev txiav txim ntau. Peb muab tag nrho cov kev taw qhia kev txhim kho thiab ua haujlwm tau zoo thiab txhawj xeeb-dawb tom qab- muag cov lus teb.
Cim npe nrov: 4 txoj kev valve, Tuam Tshoj, Hoobkas, lwm tus neeg, manufacturers, neeg muag khoom, lag luam wholesale, hais
