Roj Dawb Cua Compressor Rau Tsheb
Txais yuav cov roj qib siab- cov qauv dawb scroll, peb lub tshuab compressor muab cov roj muaj ntawv pov thawj Class 0- huab cua dawb kom ua tau raws li cov qauv thoob ntiaj teb nruj. Nws muaj kev ua tau zoo ntawm lub zog, ultra- tsis tshua muaj suab nrov, thiab kev ua haujlwm ruaj khov, ua kom muaj kev ruaj khov thiab txhim khu kev qha. Kev saib xyuas - tsim qauv pub dawb thiab kev tsim kho kom ruaj khov qis dua tag nrho cov nqi khiav lag luam. Compact thiab yooj yim rau nruab, nws yog qhov zoo tshaj plaws kev xaiv rau precision industries xws li kev kho mob, khoom noj khoom haus, electronics thiab laboratories.
Hauj lwm lawm
Yog tias koj tab tom nrhiav rau cov roj tsis muaj cua compressor rau tsheb, txais tos rau cov khoom muag los ntawm peb lub hoobkas. Raws li ib qho ntawm cov ua lag luam thiab cov muag khoom nyob rau hauv Suav teb, peb yuav muab koj cov kev pabcuam zoo tshaj plaws thiab xa khoom sai. Tam sim no, xyuas cov lus hais nrog peb tus neeg muag khoom.
Roj-Pub Dawb Cua Compressor rau Tsheb
Khoom Description
Lub tshuab cua compressor yuav tsum tau muab cia rau hauv qhov chaw qhuav, zoo - qhov cua nyob sab hauv tsev, nruj me ntsis zam kev sib cuag nrog corrosive, perishable, flammable, lossis tshuaj lom neeg.
Kev cuam tshuam tiag tiag yog txwv tsis pub. Thaum siv, nws yuav tsum tau muab tso rau kom tsis txhob tilting los yog inversion, uas yuav ua rau malfunctions thiab xwm txheej.
Txhawm rau kom muaj kev nyab xeeb thiab txuas lub tshuab lub neej ntev, lub tshuab yuav tsum tau muab tso rau hauv qhov dej - qhov cua, huv si, thiab qhov chaw txias. Lub ambient kub yuav tsum nyob rau hauv thaj tsam ntawm -40℃mus rau 60 degree. Tsis txhob siv nws nyob rau hauv ib puag ncig uas muaj pa phem, plua plav, lossis roj fumes.
Ua ntej txuas rau lub hwj chim, xyuas kom meej tias lub tshuab raug kaw. Ua haujlwm lub tshuab raws li cov lus qhia. Voltage fluctuations raug tso cai yog ± 10%. Rau kev nyab xeeb, tsis txhob kov tej yam khoom ntawm lub tshuab cua compressor thaum nws ua haujlwm.
| Qhov nruab nrab compression | Cua nruab nrab | |
| Ua hauj lwm siab | Suction siab | Atmospheric siab |
| Tshem tawm siab | 0 ~ 12.5Mpa | |
| Lub zog rau ntws piv | Tsawg dua los yog sib npaug rau 12 (nrog rau lub cev muaj zog thiab tswj) | |
| Kub | Kub | -40℃~ +65 degree |
| Suction kub | -40℃~ +65 degree | |
| Tshem tawm kub | Tsawg dua lossis sib npaug li 90℃+ Ambient kub (Dej txias) | |
Cov ntaub ntawv qhia txog scroll- hom roj -dawb cua compressor
| Compressor style | Roj-dawb scroll cua compressor |
| Qhov nruab nrab compression | Cua |
| Ib txwm ceev | 1800-3200 rpm |
| Lub zog hluav taws xob | 380VAC Peb-theem |
| Compressor txias txoj kev | Forced dej txias |
| Qhov hnyav | 44kg (nrog rau lub cev muaj zog thiab tswj) |
| Plhaub | Electroplating ntawm aluminium qhov chaw |
| Txoj kev teeb tsa | Bolt kev twb kev txuas |
| Installation loj | Kos duab 4 - M10 mounting txoj hauj lwm thiab lub cev muaj zog hlau waterproof connector |
| Daim ntawv dimension | 334*300*354 |
| Suction yeeb nkab puab loj | Sab nraud txoj kab uas hla Φ25 |
| Exhaust yeeb nkab puab loj | Φ25 M22 * 1.5 Compression haum |
| Hydraulic siab ntawm coolant | 1bar |
| Sab nraud coolant flow rate | Ntau tshaj lossis sib npaug li 10L / min |
| Coolant inlet kub | Tsawg dua lossis sib npaug li 65 degree |
Compression kev ua tau zoo
| Ceev (rpm) | 3200 |
| Rated ntws (L / min) | Ntau dua lossis sib npaug rau 480 |
|
Kev siv hluav taws xob (KW) |
Tsawg dua los yog sib npaug rau 5.8 (nrog rau lub cev muaj zog thiab tswj) |
| Lub zog rau ntws piv | Tsawg dua los yog sib npaug rau 12 (nrog rau lub cev muaj zog thiab tswj) |
suab nrov
| Ceev (rpm) | 3200 |
| Lub suab nrov, dB (A) | Tsawg dua los yog sib npaug li 65 |
Cov Khoom Paub meej
 |
 |
Cov txheej txheem daws teeb meem
Ua ntej kev daws teeb meem, cov khoom siv hluav taws xob yuav tsum raug txiav. Nco ntsoov tshem tawm cov khoom siv hluav taws xob tseem ceeb thiab tso tawm lub siab hauv lub tshuab cua compressor ua ntej yuav kho lossis kho.
Lub tshuab cua compressor tsuas tuaj yeem kuaj xyuas tom qab nws tau txias mus rau qhov kub uas nws tuaj yeem kov tau ntawm tes. Tsis txhob siv dej txias kom txias ncaj qha.
